Specifications*
  • Body Dimensions
  • Length2020 mm
  • Width820 mm
  • Height1230 mm
  • Wheel base1350 mm
  • Ground clearance160 mm
  • Kerb weightSTD-141 KG; DD-143 KG
  • Fuel tank capacity12 L
  • Engine
  • TypeAir cooled, 4-Stroke, SI
  • Displacement162.71 cc
  • Max net power
  • Max net torque
  • Bore 57.300 mm
  • Stroke63.096 mm
  • Compression ratio10.0:1
  • Air filter typeViscous paper filter
  • Starting methodSelf / Kick
  • Transmission
  • No of gears5
  • Gear pattern1-N-2-3-4-5
  • Max speed110 Kmph
  • Tyres & Brakes
  • Tyre Size (Front)80/100-17
  • Tyre Size (Rear)130/70-17
  • Tyre Type (Front)Tubeless
  • Tyre Type (Rear)Tubeless
  • Brake Type & Size (Front)Petal Disc 276 mm
  • Brake Type & Size (Rear)Drum 130 mm; Disc 220 mm
  • Frame & Suspension
  • Frame typeDiamond
  • FrontTelescopic
  • RearMonoshock
  • Electricals
  • Battery12V 4Ah (MF)
  • Head lampLED

^Service more frequently when riding in unusually wet or dusty areas.
*The specifications and design of the motorcycle show may vary according to requirements & conditions and are subject to change without any notice. Accessories shown in the picture are not a part of the standard equipment.
